EVERVIEW EV2700MDW - Step 4: Wall Plate and Extensions

d
07
08
01
07
08
for 18”to 24”space studs
for studs with the sapce between 16.5” to 18”
Step 4 Attach the Extensions to the Wall Plate
Only one side need to attach each of
extensions A and B.
Extension A
Extension BExtension BExtension B
c
d
a
step2
b
step1
a
M6
a(12PCS)
M6X12MM
b(4PCS)
M6X14MM
c(8PCS)
M6
d(8PCS)
allen wrench
4x4
e(1PC)
allen wrench
f(1PC)
