EVGA supernova G3 series User Manual

12
Deutsch
550W / 650W GOLD
Netzteil Bedienungsanleitung
Maße: 85mm (H) x 150mm (W) x 150mm (L)
Darunter: Überspannungsschutz, Unterspannungsschutz, Überlastschutz,
Kurzschlussschutz, Überstromschutz, Überhitzungsschutz.
SuperNOVA 550 / 650G3 Kabelkonfiguration
Modular Connector
MB
CPU1
VGA1
VGA2
SATA1
SATA2
PERIF1
FDD
Kabel Farbe
Schwarz
Kabel
SuperNOVA 550 / 650G3 Spezifikationen
+50°C ambient @ full load
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240 VAC, 10A, 60/50 Hz
+5V +3.3V +12V -12V +5Vsb
22A 22A 45.8A 0.5A 3A
110W 549.6W
6W 15W
550W @ +50°C
+50°C ambient @ full load
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240 VAC, 10A, 60/50 Hz
+5V +3.3V +12V -12V +5Vsb
22A 24A 54.1A 0.5A 3A
110W 649.2W
6W 15W
650W @ +50°C
2 x SATA 5-Pin x 3
1 x EPS/ATX12V 8(4+4)-Pin
1 x PCI-E 8(6+2)-Pin
1 x ATX 24-Pin
1 x PCI-E 8(6+2)-Pin x 2
1 x Molex 4-Pin x 4
1 x Molex to FDD Adapter
SuperNOVA 650W GOLD
SuperNOVA 550W GOLD

EVGA supernova G3 series Specifications

General

Series	SuperNOVA G3
Efficiency Rating	80 PLUS Gold
Form Factor	ATX
Wattage	550W, 650W, 750W, 850W, 1000W
Fan Size	130mm
Fan Bearing Type	Hydraulic Dynamic Bearing
Over Voltage Protection	Yes
Under Voltage Protection	Yes
Over Power Protection	Yes
Over Temperature Protection	Yes
Short Circuit Protection	Yes
Over Current Protection	Yes
Modular	Full Modular
Molex Connectors	3 to 6 (varies by wattage)
EPS Connectors	1 or 2 (varies by wattage)
ATX Connector	1
Warranty	7-10 Years (varies by region)
