650W / 750W / 850W /1000W GOLD
Power Supply User Manual
Introduction: Premium Power
What’s in the Box
Included with your EVGA SuperNOVA 650 / 750 / 850 / 1000 G6 power supply are the following items for proper
installation and optional testing:
2
650 G6
(1) EVGA Power Supply
(1) EVGA Manual
(4) Mounting Screws
(1) EVGA PSU Tester (24-Pin)
(1) 24-Pin ATX Cable
(1) 8(4+4)-Pin EPS/ATX12V CPU Cable
(1) 2 x 8(6+2)-Pin PCI-E VGA Cable
(2) 3 SATA Cables
(1) 4 Molex Cable
(1) Molex to FDD Adapter
(1) Power Cord Cable (optional)
(1) EVGA Power Supply
(1) EVGA Manual
(4) Mounting Screws
(1) EVGA PSU Tester (24-Pin)
(1) 24-Pin ATX Cable
(2) 8(4+4)-Pin EPS/ATX12V CPU Cables
(2) 8(6+2)-Pin PCI-E VGA Cables
(2) 2 x 8(6+2)-Pin PCI-E VGA Cables
(3) 3 SATA Cables
(1) 4 Molex Cable
(1) Molex to FDD Adapter
(1) Power Cord Cable (optional)
(1) EVGA Power Supply
(1) EVGA Manual
(4) Mounting Screws
(1) EVGA PSU Tester (24-Pin)
(1) 24-Pin ATX Cable
(2) 8(4+4)-Pin EPS/ATX12V CPU Cables
(3) 2 x 8(6+2)-Pin PCI-E VGA Cables
(4) 3 SATA Cables
(1) 4 Molex Cable
(1) Molex to FDD Adapter
(1) Power Cord Cable (optional)
750 / 850 G6 1000 G6
Safety Information
WARNING1: This unit has no user-serviceable parts inside. Opening the casing presents a risk of electrocution and will void the product’s warranty.
WARNING2:Only use included cables or cables purchased from EVGA.com that are specifically labeled for your PSU.
Using incorrect cables runs the risk of catastrophic failure.
EVGA will not be responsible for any result of improper use, including but not limited to, any use of the product outside of its intended purpose
or use inconsistent with the warranty terms available online. (Warranty information is available at www.evga.com/support/warranty and this
manual is available at www.evga.com/manuals
).
Introducing the EVGA G6 Power Supplies – the new standard for today’s high-powered PC components. As current
and future PC hardware demands more power, EVGA G6 power supplies rise to the challenge to provide rock-solid
stability and relentless efficiency without sacrificing performance or size. EVGA G6 power supplies are fully modular
at only 140mm long, feature 100% Japanese capacitors, built with a full bridge/LLC Resonant/DC-DC design, and
ensure silent operation with EVGA ECO Mode and a 135mm FDB fan. Backed with a full-suite of protections and
EVGA’s 10-Year Limited Warranty, the EVGA G6 have officially landed.
(1) 8(6+2)-Pin PCI-E VGA Cable
(2) 8(6+2)-Pin PCI-E VGA Cables
3
English
650W / 750W / 850W / 1000W GOLD
Power Supply User Manual
Installation
Features
STABLE POWER
The G6 series has outstanding electrical performance with ultra stable voltage and extremely clean power
output.
This can help you achieve the highest possible overclock (optional) and provide the most stable and reliable power
to all components. The G6 series also has high efficiency up to 90% (115V~) / 92% (230V~) efficiency
and is
80 PLUS
®
GOLD certified.
ECO THERMAL CONTROL SYSTEM
The EVGA ECO Intelligent Thermal Control System provides silent operation at low loads, improved efficiency
and longer life span of the fan. Enabled by a simple switch directly on the power supply, the “No Fan Spin” feature
is ideal for users looking to reduce ambient noise overall. Save on energy costs and unnecessary fan usage with
the EVGA ECO Thermal Control System.
TOP QUALITY PROTECTIONS
The G6 series comes equipped with the most comprehensive protection set possible, including Over Voltage
Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), Short Circuit Protection (SCP),
Over Current Protection (OCP), and Over Temperature Protection (OTP). This product is also covered by an
exceptional 10-year warranty and EVGA’s legendary customer service and support.
SUPERIOR BUILD QUALITY
The G6 series is built to the highest standards, using 100% Japanese capacitors rated at 105 degrees Celsius
and high quality brand-name semiconductor components for the highest performance and reliability. The Ultra
Quiet 135mm Fluid Dynamic Bearing fan provides adequate cooling to allow near silent operation.
MODULAR DESIGN
Reduce clutter in the case, improve ambient temperatures with better airflow overall and provide a clean look to
any system. Modular PSU designs allow the user to disconnect the cables from the power supply side if they are
not needed for the specific configuration. This can help free up space inside the case and improve cable
management as well as airflow throughout the system.
1. Remove the power supply from its packaging.
2. (Optional) Using the provided PSU testing tool, connect the 24-Pin cable to the
PSU, then attach the testing tool to the 24-Pin cable. Connect the ATX power cable
to the PSU and plug the PWR cable into the outlet or surge protector/UPS you plan
to use. Once connected, turn the power switch to the ON position. (If the ECO
mode is set to ON, the fan will not spin)
Please note: If you are using a water cooling configuration, this testing tool
provides a simple, safe, option for bleeding/draining/testing water cooling
components without the need of a paperclip or other device.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
