Features
Installation
1. Remove the power supply from its packaging.
2.
The G7 series has outstanding electrical performance with ultra stable voltage and extremely clean power output.
This can help you achieve the highest possible overclock (optional) and provide the most stable and reliable power
to all components. The G7 series also has high eciency up to 90% (115V~) / 92% (230V~) eciency and is 80
PLUS
®
GOLD certified.
STABLE POWER
03
ECO THERMAL CONTROL SYSTEM
The EVGA ECO Intelligent Thermal Control System provides silent operation at low loads, improved eciencyand
longer life span of the fan. Enabled by a simple switch directly on the power supply, the “No Fan Spin” feature is
ideal for users looking to reduce ambient noise overall. Save on energy costs and unnecessary fan usage with the
EVGA ECO Thermal Control System.
TOP QUALITY PROTECTIONS
The G7 series comes equipped with the most comprehensive protection set possible, including Over Voltage
Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), Short Circuit Protection (SCP),
Over Current Protection (OCP), and Over Temperature Protection (OTP). This product is also covered by an
exceptional 10-year warranty and EVGA’s legendary customer service and support.
SUPERIOR BUILD QUALITY
The G7 series is built to the highest standards, using 100% Japanese capacitors rated at 105 degrees Celsius and
high quality brand-name semiconductor components for the highest performance and reliability. The Ultra Quiet
120 mm Fluid Dynamic Bearing fan provides adequate cooling to allow near silent operation.
MODULAR DESIGN
Reduce clutter in the case, improve ambient temperatures with better airflow overall and provide a clean look to
any system. Modular PSU designs allow the user to disconnect the cables from the power supply side if they are
not needed for the specific configuration. This can help free up space inside the case and improve cable management
as well as airflow throughout the system.
SYSTEM LOAD INDICATOR BARS
The G7 series features real-time system load indicator bars on the side of the power supply to display the current
system load of the power supply in 20% increments. The first indicator light notifies you that your system load is
between 0-20% of its rated wattage. The second bar will light up to notify you that you are using between
20-40% of the rated system wattage, and each successive bar will light up once it attains the next 20% of its
rated wattage. If the fifth bar lights up, this means that you are using between 80-100% of the rated wattage and
you should consider upgrading to a higher wattage power supply.
(Optional) Using the provided PSU testing tool, connect the 24-Pin cable to the
PSU, then attach the testing tool to the 24-Pin cable. Connect the ATX power
cable to the PSU and plug the PWR cable into the outlet or surge protector/UPS
you plan to use. Once connected, turn the power switch to the ON position. (If
the ECO mode is set to ON, the fan will not spin)
Please note : If you are using a water cooling configuration, this testing tool
provides a simple, safe, option for bleeding/ draining/ testing water cooling
components without the need of a paperclip or other device.
