EVGA SUPERNOVA GM Series User Manual

English
2
3
English
l
Power Supply User Manual
Introduction: Premium Power
Introducing the EVGA SuperNOVA GM line. These new power supplies are engineered to bring the power, prestige,
and performance of EVGA’s award-winning power supplies – into an SFX form factor. Designed with fully modular
cables, the GM series brings big performance to small spaces. Built with 80 PLUS Gold certified efficiency, reliable
Japanese Capacitors , a quiet 92mm fan, and EVGA’s 7/10 Year warranty and unparalleled Customer Service, the
EVGA SuperNOVA GM power supplies makes short work of tight spaces.
450 GM
(1) EVGA Power Supply
(1) EVGA Manual
(8) Mounting Screws
(1) EVGA PSU Tester (24-Pin)
(1) ATX bracket
(1) 24-Pin ATX Cable
(1) 8(4+4)-Pin EPS/ATX 12V CPU Cable
(1) 2 x 8(6+2)-Pin PCIe VGA Cable
(1) 4 SATA Cable
(1) 4 Molex Cable
(1) Molex to FDD Adapter
(1) Power Cord Cable (optional)
550 GM
(1) EVGA Power Supply
(1) EVGA Manual
(8) Mounting Screws
(1) EVGA PSU Tester (24-Pin)
(1) 24-Pin ATX Cable
(1) ATX bracket
(1) 8(4+4)-Pin EPS/ATX 12V CPU Cable
(2) 2 x 8(6+2)-Pin PCIe VGA Cables
(1) 4 SATA Cable
(1) 4 Molex Cable
(1) Molex to FDD Adapter
(1) Power Cord Cable (optional)
(1) EVGA Power Supply
(1) EVGA Manual
(8) Mounting Screws
(1) EVGA PSU Tester (24-Pin)
(1) 24-Pin ATX Cable
(1) ATX bracket
(1) 8(4+4)-Pin EPS/ATX 12V CPU Cable
(2) 2 x 8(6+2)-Pin PCIe VGA Cables
(2) 3 SATA Cables
(1) 4 Molex Cable
(1) Molex to FDD Adapter
(1) Power Cord Cable (optional)
650 GM
750 GM
(1) EVGA Power Supply
(1) EVGA Manual
(8) Mounting Screws
(1) EVGA PSU Tester (24-Pin)
(1) ATX bracket
(1) 24-Pin ATX Cable
(2) 8(4+4)-Pin EPS/ATX 12V CPU Cables
(2) 2 x 8(6+2)-Pin PCIe VGA Cables
(2) 3 SATA Cables
(1) 4 Molex Cable
(1) Molex to FDD Adapter
(1) Power Cord Cable (optional)
850 GM
(1) EVGA Power Supply
(1) EVGA Manual
(8) Mounting Screws
(1) EVGA PSU Tester (24-Pin)
(1) 24-Pin ATX Cable
(1) ATX bracket
(2) 8(4+4)-Pin EPS/ATX 12V CPU Cables
(2) 2 x 8(6+2)-Pin PCIe VGA Cables
(2) 3 SATA Cables
(1) 4 Molex Cable
(1) Molex to FDD Adapter
(1) Power Cord Cable (optional)
Only use included cables or cables purchased from EVGA.com that are specifically labeled for your PSU. Using incorrect
cables runs the risk of catastrophic failure.
Safety Information
WARNING1: This unit has no user-serviceable parts inside. Opening the casing presents a risk of electrocution and will void the
product’s warranty. EVGA will not be responsible for any result of improper use, including but not limited to, any use
WARNING2:
of the product outside of its intended purpose or use inconsistent with the warranty terms available online. (Warranty information is
available at www.evga.com/support/warranty and this manual is available at www.evga.com/manuals ).
What’s in the Box
Included with your EVGA SuperNOVA 450 / 550 / 650 / 750 / 850 GM power supply are the following items
for proper installation and optional testing:
450W / 550W / 650W / 750W / 850W GOLD
Power Supply User Manual
Installation
Features
STABLE POWER
The GM series has outstanding electrical performance with ultra stable voltage and extremely clean power
output. This can help you achieve the highest possible overclock (optional) and provide the most stable and
reliable power to all components. The GM series also has high efficiency up to 90% (115VAC) / 92% (230VAC)
efficiency and is 80 PLUS
®
GOLD certified.
ECO THERMAL CONTROL SYSTEM
The EVGA ECO Intelligent Thermal Control System provides silent operation at low loads, improved efficiency
and longer life span of the fan. The “No Fan Spin” feature is ideal for users looking to reduce ambient noise overall.
Save on energy costs and unnecessary fan usage with the EVGA ECO Thermal Control System.
TOP QUALITY PROTECTIONS
The GM series comes equipped with the most comprehensive protection set possible, including Over Voltage
Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), Short Circuit Protection (SCP),
Over Current Protection (OCP), and Over Temperature Protection(OTP) . 450 / 550 / 650 GM is also covered by a
7-year warranty and 750 / 850 GM is also covered by a 10-year warranty with EVGA’s legendary customer
service and support.
SUPERIOR BUILD QUALITY
The GM series is built to the highest standards, using Japanese capacitors rated at 105 degrees Celsius and
high quality brand-name semiconductor components for the highest performance and reliability. The Ultra Quiet
92mm fan provides adequate cooling to allow near silent operation.
improve cable
MODULAR DESIGN
Reduce clutter in the case, improve ambient temperatures with better airflow overall and provide a clean look to
any system. Modular PSU designs allow the user to disconnect the cables from the power supply side if they are
not needed for the specific configuration. This can help
free up space
inside the case and
management as well as airflow throughout the system.
1. Remove the power supply from its packaging.
2. (Optional) Using the provided PSU testing tool, connect the 24-Pin cable to the
PSU, then attach the testing tool to the 24-Pin cable. Connect the ATX power cable
to the PSU and plug the PWR cable into the outlet or surge protector/UPS you plan
to use. Once connected, turn the power switch to the “I” position.
Please note: If you are using a water cooling configuration, this testing tool
provides a simple, safe, option for bleeding/draining/testing water cooling
components without the need of a paperclip or other device.
450W / 550W / 650W / 750W / 850W GOLD

EVGA SUPERNOVA GM Series Specifications

General

Brand	EVGA
Model	SUPERNOVA GM Series
Category	Power Supply
Language	English
