Item
NO.
Description Specification QTY
1 Main Frame 1
2 Seat post 35*460*t2 1
3 Seat Slider 35*280*t2 1
4 Handlebar Post 35*280*2T 1
5 Handlebar Ø28*998*t2 1
6 Tension Bracket 1
7 Back Stabilizer Flat elliptical 30*70*2T*498L 1
8 Front Stabilizer Flat elliptical 30*70*2T*498L 1
9 Brake-handle 1
10 Felt Pad Ø10xØ25xT5 1
11 Tension Knob M10*P1.25*60 1
12 Cover (right) 1
13 Cover (Left) 1
14 Belt Cover A 1
15 Belt Cover B 1
16 Leveler M10 4
17
Plastic Sheath – inner
Pipe
Match 45*45*2 square tube
38x38 square tube
3
18 Inner cover of iron tube 30*70*2 use in elliptical tube 4
19 Inner tube plug Match 35*35*2T square tube 1
20 Front cover Use in belt driven 1
21 Transportation wheel D8*D71 5*W223 2
22 Seat 1
23 Adjusting knob M16*P1.5*35L 3
24 Φ21 plug 1
25 Inner tube plug 45*45*2T square tube 1
26
Inner hexagon hollow
screw
Φ8*M6*30 3
27 Flat washer Φ12*Φ25*1.5T 1
28 Belt 5PK54" 1
29 Tension spring Ø2.5*17 loop 1
30 Spline Shaft 1
31 Left and right crank 170 9/16"-20UNF 1
32 Crank cover 2
33 Flat washer Φ20*Φ10*1.5 4
34
Inner hexagon round head
Screw
M10x25 4
35 Left/ right pedal 9/16"-20UNF-RH 1
36 Flywheel 1
37 Flywheel axle M12*P1.0*166 1
38 PK belt wheel Ø205*19.8W 1
39 Tube cover Ø18*Ø12*34L 1
40 Pulley, Flywheel φ37*φ30*24.5 1
41 Friction brake pad 2
