Evo FX20 - Page 13

FX20 MOTORIZED TREADMILL
Visit us at: www.evofitness.com
13
ASSEMBLY
STEP 4:
Slide the Handlebar Cover – Left #2 (8) and Handlebar Cover – Right #2 (9) onto the Front Handlebar (6). Connect
each of the EKG Pulse Wire (13) to each of the EKG Pulse Sensor (5).
Secure the Front handlebar (6) to the Handlebar (97) using two M8 x 30mm Screw (100).
