FX20 MOTORIZED TREADMILL
Visit us at: www.evofitness.com
15
ASSEMBLY
STEP 6:
Attach the Upright Base Cover – Left #2 (18) and Upright Base Cover – Left #1 (17) over the Left Upright (15). Secure
using three Plastic Fixing Insert (72) and three M4 x 15mm Screw (70). Attach the Upright Base Cover – Right #2 (19)
and Upright Base Cover – Right #1 (20) over the Right Upright (16). Secure using three Plastic Fixing Insert (72) and
four M4 x 15mm Screw (70).
