EVO REV 600 ELLIPTICAL TRAINER
Visit us at: www.evofitness.com
4
PARTS LIST
No. Description Qty. Order No.
No. Description Qty. Order No.
1 Computer 1 REV600-001
30 20 x 91 x M14mm Bolt 2 REV600-030
2 Console Housing - Upper 1 REV600-002
31 Bearing 6804zz 4 REV600-031
3 Console Housing - Bottom 1 REV600-003
32 Level Adjusters 2 REV600-032
4 Accessory Tray Front Cover 1 REV600-004
33 Pedal Arm - Left 1 REV600-033
5 Side Upright - Left 1 REV600-005
34 Pedal Arm - Right 1 REV600-034
6 Side Upright - Right 1 REV600-006
35 C clips 2 REV600-035
7 Handrail - Left 1 REV600-007
36 Bearing 2202zz 2 REV600-036
8 Handrail - Right 1 REV600-008
37 Pedal Arm Bushing 2 REV600-037
9 Fixed Handle Bar End Cap 2 REV600-009
38 Metal Bushing 2 REV600-038
10 Action Handle Bar End Cap 2 REV600-010
39 Pedal Arm Rear Shaft 2 REV600-039
11
Action Handle Bar Shaft
Bushin
g
#1
2 REV600-011
40 Plastic Spacer 2 REV600-040
12
Action Handle Bar Shaft
Bushin
g
#2
2 REV600-012
41 Action Handle Bar Shaft 1 REV600-041
13 Action Handle Bar Cover 2 REV600-013
42 Upright 1 REV600-042
14 Action Handle Bar Front Cover 4 REV600-014
43 M3 x 15mm Screw 4 REV600-043
15 Bearing 6004zz 4 REV600-015
44 Rubber Ring 2 REV600-044
16 Action Handle Bar - Left 1 REV600-016
45 Accessory Tray 1 REV600-045
17 Action Handle Bar - Right 1 REV600-017
46
Electro-magnetic System
Bracket Fixin
g
Bolt
1 REV600-046
18 Pedal Arm Front Pivot Cover 4 REV600-018
47 Power Plate Bracket 1 REV600-047
19 Fixed Handle Bar Foam Grip 2 REV600-019
48 Electro-magnetic System 1 REV600-048
20 Action Handle Bar Foam Grip 2 REV600-020
49
Electro-magnetic System
Bracket
1 REV600-049
21 Hand Pulse Sensor with wire 2 REV600-021
50 Crank Disk Rubber Cap 2 REV600-050
22 Pedal Soft Cushion 2 REV600-022
51 Crank Disk 2 REV600-051
23 Pedal 2 REV600-023
52 Belt 1 REV600-052
24 Pedal Support Base 2 REV600-024
53 Aluminum Disk 1 REV600-053
25 Pedal Buffer Set 2 REV600-025
54 Flywheel 1 REV600-054
26 Bearing 608zz 8 REV600-026
55 3/4" Nut 2 REV600-055
27 Bushing 8 x 12mm 4 REV600-027
56 Flywheel Axle 1 REV600-056
28 Pedal Fixing Base 2 REV600-028
57 Flywheel Axle Fixing Plate 1 REV600-057
29 Pedal Cover 4 REV600-029
58 M5 x 8mm Screw 7 REV600-058
