P. 4
Please notice the scooter can travel a distance of 10km on a fully charged battery in ideal conditions. The following
are some of the major factors that will affect the operating range of your scooter.
TERRAIN: A smooth, flat surface will increase your driving distance, while driving uphill, as well as rough or uneven
terrain will reduce your distance significantly.
WEIGHT: The weight of the user can affect driving distance, a lighter user will have further range than a heavier
user.
AMBIENT TEMPERATURE: Please ride and store the scoooter under recommended temperatures, which will
increase driving distance, battery life, and overall performance of your scooter.
MAINTENANCE: Reasonable battery charging and maintenance will increase the distance. Overcharging the
battery can reduce range.
SPEED AND DRIVING STYLE: Maintaining a moderate speed will increase your distance; while travelling at high
speeds for extended periods, frequent starts, stop, idling, along with frequent acceleration and deceleration will
reduce your overall distance.
OPERATING RANGE
PARTS LIST
ABOUT YOUR NEW ELECTRIC LITHIUM SCOOTER
Net Weight: 9.3kg
Max Load: 80kg
Max Speed(km/h): 18km/h
Max Range(km): 10km
Max Incline:6-8°
Using Temperature:
0°C - 45°C
IP Grade: IPX4
Weight:
Scooter:
Motor:
Battery:
Charger:
Materials
&
Size:
Thank you for purchasing our product. Keep these points in mind as you read this guide:
Material: Steel & Alu.
Folded Size(mm):
950*425*350mm
Unfolded Size(mm):
950*425*1000mm
Rated input (V/A):
100-240VAC 50/60Hz 1.8A
Rated output voltage: 29.4V
Current: 2.0A
Charging time(H):
3-4Hours
Model No.: FY0632942000
Plug: Type G
Rated voltage: 25.2V
Capacity(Ah): 4.0Ah
Rated power(W): 250W
Front Wheel Size: 6inch
Rear Wheel Size: 6inch
Handlebar
1
Hex Key
2
1
1
1
1
pair
Instruction
Manual
PART
NO.
PART
NAME
PICTURE REMARKS
QTY
(pcs)
1
3
5
2
4
Left &
right
Body
5mm
3mm
Charger
PART
NO.
PART
NAME
PICTURE REMARKS
QTY
(pcs)
To Next Page
