EVO XPLORE ELLIPTICAL TRAINER
Visit us at: www.evofitness.com
5
PARTS LIST
No. Description Qty. Order No. No. Description Qty. Order No.
59 Left Foot Pedal 1 XPLORE-59
60 Left Foot Pedal Tube 1 XPLORE-60
61 M6 x 13mm Washer 4 XPLORE-61
62 Foot Pedal Knob 4 XPLORE-62
63 Nut Cover - 38mm 2 XPLORE-63
64 #8 x 15mm Screw 8 XPLORE-64
65 Safety Spacer 2 XPLORE-65
66 M10 x 88mm Carriage Bolt 2 XPLORE-66
67 Oval Head Plug 2 XPLORE-67
68 Right Cover 1 XPLORE-68
69 Left Cover 1 XPLORE-69
70 M8 x 22mm Allen Head Bolt 8 XPLORE-70
71 Rear Cap w/ Height Adjustment 2 XPLORE-71
72 Rear Stabilizer 1 XPLORE-72
73 Front Foot Cap with Wheel (L) 1 XPLORE-73
74 Front Stabilizer 1 XPLORE-74
75 Front Foot Cap with Wheel (R) 1 XPLORE-75
76 Gear Box 1 XPLORE-76
77 Right Foot Pedal Tube 1 XPLORE-77
78 Right Foot Pedal 1 XPLORE-78
79 Nut Cover - 32mm 2 XPLORE-79
80 Adaptor 1 XPLORE-80
81 Upper Computer Wire 1 XPLORE-81
82 Lower Computer Wire 1 XPLORE-82
83 Hand Pulse Sensor Wire 2 XPLORE-83
84 Spring Washer 8 XPLORE-84
85 M10 x 20mm Washer 2 XPLORE-85
86 M8 x 16mm Washer 4 XPLORE-86
87 Nut Cover – 13mm 4 XPLORE-87
88 M10 Nylon Nut 2 XPLORE-88
