EVO XPLORE ELLIPTICAL TRAINER
Visit us at: www.evofitness.com
4
PARTS LIST
No. Description Qty. Order No. No. Description Qty. Order No.
1 M10 Nut 2 XPLORE-01 30 Crank Disk 2 XPLORE-30
2 M6 x 8mm Screw 4 XPLORE-02 31 Crank Frame 2 XPLORE-31
3 Flywheel Axle Holder 2 XPLORE-03 32 #8 x 15mm Screw 8 XPLORE-32
4 Jockey Wheel Bracket 1 XPLORE-04 33 C - Holder Buckle 2 XPLORE-33
5 Washer 1 XPLORE-05 34 Bearing (6004zz) 2 XPLORE-34
6 E - Holder Buckle 1 XPLORE-06 35 Crank Shaft 1 XPLORE-35
7 Flywheel Axle 1 XPLORE-07 36 Dual Action Cap 2 XPLORE-36
8 Bearing (6000zz) 2 XPLORE-08 37 Rubber Grip 2 XPLORE-37
9 Small Belt Pulley 1 XPLORE-09 38 Left Dual Action Handle 1 XPLORE-38
10 M8 x 15 CAP Screw 4 XPLORE-10 39 Right Dual Action Handle 1 XPLORE-39
11 Spring Washer 4 XPLORE-11 40 Computer 1 XPLORE-40
12 Aluminum Disk 1 XPLORE-12 41 Fixed Handle Rubber Grip 2 XPLORE-41
13 Flywheel 1 XPLORE-13 42 Hand Pulse Sensor 2 XPLORE-42
14 M10 x 16mm Washer 1 XPLORE-14 43 M6 x 15mm Screw 4 XPLORE-43
15 M8 Nut 1 XPLORE-15 44 M8 Nylon Nut 4 XPLORE-44
16 M6 x 15mm Screw 2 XPLORE-16 45 Curved Washer 8 XPLORE-45
17 Bearing (6300zz) 2 XPLORE-17 46 Nut Cover - 50mm 2 XPLORE-46
18 M6 x 12mm Screw 1 XPLORE-18 47
M8 x 15mm Hex Head
Sc
r
ew
4 XPLORE-47
19 Jockey Wheel Spring 1 XPLORE-19 48 M8 x 30mm Washer 2 XPLORE-48
20 Magnet Bracket Spring 1 XPLORE-20 49 Bushing - 50mm 6 XPLORE-49
21 M10 x 22mm Washer 2 XPLORE-21 50 M8 x 48mm Carriage Bolt 4 XPLORE-50
22 Spring 1 XPLORE-22 51 Left Dual Action Arm 1 XPLORE-51
23 Magnet Bracket Shaft 1 XPLORE-23 52 Upright Support 1 XPLORE-52
24 Magnet Bracket 1 XPLORE-24 53 Right Dual Action Arm 1 XPLORE-53
25 #3 x 8mm Screw 2 XPLORE-25 54 Bushing - 38mm 4 XPLORE-54
26 Speed Box 1 XPLORE-26 55 Action Arm Shaft 2 XPLORE-55
27 Main Frame 1 XPLORE-27 56 M8 x 32mm Washer 2 XPLORE-56
28 Belt 1 XPLORE-28 57 Bushing - 32mm 4 XPLORE-57
29 Crank Disk Insert 2 XPLORE-29 58 M8 x 60mm Carriage Bolt 4 XPLORE-58
