Care & Maintenance
13
Adjusting Brakes
EVOLV Pro / Pro Plus
Small adjustments can be made at the barrel adjuster on the brake lever, but all major
adjustments should be made at the opposite end of the cable at the brake caliper.
With the barrel adjuster on the brake lever threaded almost all the way in, adjustments
can then be made to the front or rear caliper. If your brakes are too loose, you will
need to increase tension on the brake cable.
To do this, using a 5mm hex tool, loosen the screw holding down the cable near the
caliper. While holding the cable, rotate the brake arm in the direction of the scooter
until it can’t go any further, making sure to keep tension on the brake cable. Once the
arm stops rotating, rotate in the opposite direction a small amount and tighten down
the screw.
If your brakes are too tight, check that nothing is interfering with the brake cable
between the handlebars and the caliper. Follow the directions listed above, only
remove tension on the brake cable instead of introducing it.
EVOLV Pro - R
Hydraulic brake systems require less maintenance, but do need to be bled from time
to time in order to stay at peak performance levels. Bleeding the system involves
removing any built up air in the hoses and topping off the hydraulic uid and requires a
hydraulic brake bleeding kit.
If you are not comfortable doing this yourself, reach out to your dealer for further
directions.
Product Specication
Product Name EVOLV Pro / Pro Plus / Pro - R
Motor (Individual) 52V Dual 1000Watt per Motor (Pro and Pro Plus)
60V Dual 1200Watt per Motor (Pro - R)
Motor Cover Material Aluminum Alloy
Peak Power Output
(Combined)
2600W Peak (Pro and Pro Plus) / 3000W peak (Pro - R)
Max Speed 65 km/h / 40 mph (Pro and Pro Plus)
70 km/h / 44 mph (Pro - R) (Check local laws before use)
Max Mileage 60 - 65 km / 37 - 40 mi (Pro)
80 - 85 km / 50 - 53 mi (Pro Plus)
65 - 70 km / 40 - 43 mi (Pro - R)
Battery Type Lithium-ion Battery
Battery Capacity 52V 18.2AH (Pro) / 52V 23Ah (Pro Plus)
60V 21 AH (Pro - R)
Lights Dual Head Lights & Dual LED Taillight
Braking Front and Rear Mechanical Disc Brake System (Pro and Pro Plus)
Front and Rear Hydraulic Disc Brake System (Pro - R)
Tires 10 Inch Pneumatic Front and Rear Tires
Suspension Front and Rear Spring
Dashboard Blue Smart Display
Display Functions Battery, Trip, ODO, Speed, Mode, and Voltage
Folding Dual Lever Clamp
Body Frame Aluminum Alloy
Covers Material Polypropylene
Max Rider Weight 150 kg / 330 lbs
Product Size 128 * 50 * 25.4 cm
Product Weight 35 kg / 77 lbs (Pro and Pro Plus)
36 kg / 80 lbs (Pro - R)
Box Size 106 * 26 * 44 cm
14
