AirKey system manual version 2.7 |
06/03/2024 | Subject to technical changes and misprints
13 Locking components signals
The locking components indicate events with a host of visual and audible signals.
Signal
number
Event
Visual
signal
*)
Audible
signal
*)
Note
Signal 1
Unlocking process
with authorised
medium
⚫⚫⚫⚫⚫
mmmmm
Signal 2
End of release
duration
⚫⚫⚫⚫⚫
lllll
Signal 3
Unlocking process
with unauthorised
medium
⚫⚫-⚫⚫-⚫⚫-⚫⚫
hh-hh-hh-hh
Signal 7
"Battery empty"
warning
(Shown in the AirKey
Online Administration
in the table of the
locking components
and in the details of a
locking component as
"battery empty"
symbol)
⚫⚫--⚫⚫--⚫⚫--⚫⚫
h----h----h----
h
The signal is
output upon
inserting empty
batteries instead
of signal 8 and
upon unlocking
before signal 1.
1000 unlocking
processes or two
weeks of standby
mode are gua-
ranteed following
the first signals
(at room tempe-
rature and when
using cards, key
fobs, combi keys
or wristbands).
Signal 8
Insert new batteries
or component restart
⚫⚫--⚫⚫--⚫⚫
ll--mm--hh
Signal 9
Medium without EVVA
segmentation;
external medium
⚫⚫⚫
None
No longer in use.
Only signal 3 is
used for this
purpose.
Signal 10
Locking component
communication or
hardware error
⚫--⚫--⚫--⚫--⚫--
⚫--⚫--⚫--⚫--⚫--
⚫--⚫--⚫--⚫--⚫--
⚫--⚫--⚫--⚫--⚫
mmm---mmm---
mmm---mmm---
mmm---mmm---
mmm---mmm---
mmm---mmm
For instance,
indicates a faulty
connection
between a
cylinder’s thumb
turn and electro-
nics module.
