LAVADORA EVVO NOVA 8/9/10/11/12 X
58
ENGLISH
Water injecting problem
during wash cycle.
Check if the water
pressure is high enough.
Straighten the water pipe.
Clean the inlet valve filter.
6. TECHNICAL SPECIFICATIONS
Fig. 21
Model Nova 8 Nova 9 Nova 10 Nova 11 Nova 12
Power Supply 220 - 240V, 50Hz
MAX. Current 10A
Standart Water
Presure
0.05 MPa - 1 MPa
Washing Capacity 8.0Kg 9.0Kg 10.0Kg 11Kg 12Kg
Dimension
A 595mm 595mm 595mm 595mm 595mm
B 850mm 850mm 850mm 850mm 850mm
C 475mm 535mm 535mm 565mm 595mm
Weight 63kg 65kg 65kg 72kg 76kg
Rated Power 1900W 1950W 1950W 1950W 2000W
Reference Dimen-
sion
