Excel Dryer ThinAir TA-ABS - Troubleshooting Codes and Parts List; Code Chart; Parts List

EXCEL DRYER, INC 1.800.255.9235 EXCELDRYER.COM ADMIN@EXCELDRYER.COM
357 CHESTNUT STREET, EAST LONGMEADOW, MA 01028
3/2018
4
READ AND SAVE THESE INSTRUCTIONS
TA-1 Cover(includesnameplate)
TA-2 Tamper-ProofBolt
TA-3 Tamper-ProofWrench
TA-4 KnockoutGasket
TA-5 BracketCoverHook
TA-6 Nozzle
TA-7 OpticBracket
TA-8 OpticAssembly
TA-9 FingerGuard
TA-10 HeatingElementAssembly
TA-11 MuferHousing(output)
TA-12 MuferFoam(output)
TA-13 MotorGasketRing
TA-14 ClamshellUpper
TA-15 BracketCover
TA-16 ControlAssembly
TA-17 Motor
TA-18 MotorGasket
TA-19 Pre-lter(includesscreen)
TA-20 MuferFoam(input)
TA-21 MuferHousing(input)
TA-22 Clamshell(lower)
TA-23 BasePlate
TA-24 Nameplate
TA-25 Tube(pressure)
TA-26 TerminalBlock
PARTS LIST
Ref.No. Description
TROUBLESHOOTING (Continued)
If problem cannot be resolved with the above, please call the manufacturer at 1-800-255-9235
and one of our trained technicians will be happy to assist you.
CODE CHART
Codes are displayed by ashing the red LED in the sensor behind air outlet. Normal operation will be indicated by the red LED
being on when not drying and off when hands are under the sensor.
Dryer Maintenance Codes
1Short/1Longash CloggedPre-Filter CleanPre-Filter Dryer will still run
2Short/1Longash In lockout mode Clearobstruction Dryer stops until obstruction cleared
Motor Problem Codes
1Long/3shortashes Motorovercurrent Replacemotor Dryer will stop
1Long/4shortashes Motor under current Replacemotor Dryer will stop
Heater Problem Codes
2Long/3shortashes Shorted or incorrect heater Replaceheater Dryer will stop
2Long/4shortashes Open/broken heater Replaceheater Dryer will still run
Voltage Problem Codes
3Long/3shortashes Mainpanelovervoltage Checkincomingvoltage Dryer will stop
3Long/4shortashes Mainpanelundervoltage Checkincomingvoltage Dryer will stop
TIME TO THROW IN THE TOWEL
®
EXCEL DRYER INC • 1.800.255.9235 • EXCELDRYER.COM
2018
MARCH
18TAM0343
TA-1
TA-23
TA-2
TA-16
TA-15
TA-14
TA-24
TA-25
TA-26
TA-9
TA-7
TA-8
TA-22
TA-19
TA-20
TA-18
TA-21
TA-17
TA-3
TA-6
TA-5
TA-12
TA-13
TA-4
TA-10
TA-11
TA exploded view 4.cdr 12/13/2016 tek
TA exploded view
