EX CEL DRY ER, INC 1 . 8 0 0 . 2 5 5 . 9 2 3 5 EX CEL DRY ER. COM ADM IN@ EX CEL DRY ER. COM
3 5 7 CHESTNUT STREET, EAST L ONG M EADOW , M A 0 1 0 2 8
02/2016 2
READ AND SAVE THESE INSTRUCTIONS
W ARNING : F o r p r o p e r e l e c t r i c a l c o n n e c t i o n s , c h e c k y o u r l o c a l b u i l d i n g c o d e s .
Your unit must be installed by a qualied, licensed electrician.
P RE INSTAL L ATION W IRING
Checkthattheelectricalsupplycorrespondstothatshown
ontheratingstickerofunit.Ifthedryerisconnectedtoany
electricalsupplyotherthanthatstatedontheratingstickerof
theunit,permanentdamageorimproper,unsafeoperationof
the unit may result.
Makesureelectricityisswitchedoffatthemainpanelbefore
installing,maintainingorcleaningthishanddryer.Dryermust
be installed in accordance with current local wiring and
building regulations.
Do not wire this hand dryer into the lighting circuit. It must be
protected by an independent circuit.
Dryer is intended to be permanently connected to power
supply,andmustbeproperlygrounded.
SAF ETY
Troubleshooting and internal maintenance must be performed
byqualiedservicepersonnel.
Do not use any power wash equipment for cleaning on or
near this unit.
DonotusetheXLERATORdryerfordryinghair.
Do not obstruct air inlets or outlets.
1. Disconnectthepowersourcepreviouslybroughttothehand
dryerlocation(seepreinstallationwiringabove).
2. UsetheTamper-ProofWrenchsuppliedtoremovethe2
covermountingscrewsandliftcovertoremovefrombase
plate.
3. Ifelectricalwiringentryistobemadefromtherear,remove
theappropriatepre-formedknockoutonthebaseplate.If
entryistobemadefromthebottom,knockoutthe
pre-formedareaonthecoverforyoursupplyconnection.
Arigidconduitmustbeused.
4. Selecttheappropriatemountingheightfordryer(Table1)
andfastener,asrecommended(Table2).Thereshouldbe
noobstructionbetweenthehanddryerandtheoor.If
mountingoveracountertop,distancefromcountertodryer
mustbe15”(381mm)minimum.
CAUTION: Do not use Base Plate as a guide when drilling.
Make sure no pipe work (gas, water, air) or any electrical cables
or wires are located directly behind the area to be drilled.
5. AttachBasePlateatthefourcornerstosmoothwall.
For mostsecureinstallation,use2additionalmountingholes
asshownindrawing.Fornon-HEPAunits,removeControl
Assemblytoaccesstherightsidemountinghole.
For HEPAunits,removelteronlytoaccesstherightside
mounting hole.
6. Identifythevoltageofyourdryerfromtheratingstickerofthe
unit. Then connect to a dedicated branch circuit not
exceeding20Amp.
7. Secureelectricalwiringtoterminalsasindicatedbythe
schematicafxedtoblowerhousing.Anidentiedground
connectionpointissuppliedontheBasePlateforyour
equipment ground wire. Dryers should be installed per local
code requirements.
8. CarefullyreplaceCoverusingthe2screwspreviously
removedinstep2.Restorepowerandtestforproper
operation.Inmultipleinstallations,makesuretheserial
numbermarkedontheinsidematchesthecovernumber.
9. It is highly recommended that a bead of silicone sealant be
placedaroundtheoutsideofthecoveratthewalltoprotect
dryer from internal corrosion caused by wash water and
cleaning solutions.
10.ReturnTamper-ProofWrenchad er aal toowner.
SUG G ESTED M OUNTING HEIG HT
from oor to bottom of dryer:
Men 45"(114cm)
Women 43"(109cm)
Teenagers 41"(104cm)
SmallChildren 35"(89cm)
Handicapped 37"(94cm)
M OUNTING HARDW ARE
Re c o m m e n d e d F a s t e n e r (not supplied):
MasonryWall ½”ExpansionSleevewith¼”LagBolt
HollowWall ¼”WingTypeToggleBolt
WoodenWall ¼”LagScrewWithWasher
1 2
INSTAL L ATION INSTRUCTIONS
TABLE1 TABLE2
IM P ORTANT SAF ETY INSTRUCTIONS
ADJUSTING THE HEAT OUTPUT AND MOTOR SPEED
The dryer is shipped set at maximum heat and motor speed.
To adjust, turn the corresponding knob (H=heater, M=Motor)
on the control assembly counterclockwise to desired setting.
