Excel XL-BW - Code Chart; Dryer Maintenance Codes; Motor Problem Codes; Heater Problem Codes

TROUB L ESHOOTING ( Co n t i n u e d )
*Does not apply to XLERATOReco models
**Only applies to HEPA models
If p r o b l e m c a n n o t b e r e s o l v e d w i t h t h e a b o v e , p l e a s e c a l l t h e m a n u f a c t u r e r a t 1 - 8 0 0 - 2 5 5 - 9 2 3 5
a n d o n e o f o u r t r a i n e d t e c h n i c i a n s w i l l b e h a p p y t o a s s i s t y o u .
XL1 Cover(includesNameplate)
XL2 Nameplate
XL3 Tamper-ProofBolt
XL4 Tamper-ProofWrench
XL5 AirOutlet(includesgasket)
XL6 TerminalBlock(includesscrews)
XL7 ControlAssembly&Sensor
XL8 HeatingElementAssembly*
XL 9 Motor
XL10 BasePlateAssembly
XL11 CoverMountingBrackets
XL12 HousingGrommet
XL 13 Housing Retainer
XL15 OpticsAssembly(Sensor)
XL16 Fuseholder(ifsoequipped)
XL17 Fuse(ifsoequipped)
XL18 HEPAPre-Filter**
XL19 HEPAFilterAdapter**
XL20 HEPAFilter**
XL21 Pre-Filter
P ARTS L IST
ef o escrition
XL1
XL
2
(Location)
XL6
XL3
XL4
XL9
XL7
XL
11
(2)
XL13 (4)
XL10
XL12(4)
XL8
XL16
XL17
XL18
XL5
XL20
XL19
XL16
XL17
XL7
XL15
XL21
W / HEP
A
W / HEPA W / HEP
FILTER OPTION
DRY ER M AINTENANCE CODES
1SHORT/1LONGFLASH CloggedPre-Filter CleanPre-Filter Dryer will still run
1SHORT/2LONGFLASH SeverelycloggedPre-Filter CleanPre-Filter Dryer will stop
1SHORT/3LONGFLASH No pressure detected
Airsensortubemissingor
control not mounted correctly
Dryer will still run
2SHORT/1LONGFLASH Inlockoutmode Clearobstruction
Dryer stops until obstruction
cleared
M OTOR P ROB L EM CODES  First verify that dryer is receiving correct voltage at Terminal Block (check dryer label)
1LONG/3SHORTFLASH MotorOverCurrent Replace Motor Dryer will stop
1LONG/4SHORTFLASH MotorUnderCurrent Replace Motor Dryer will stop
HEATER P ROB L EM CODES  First verify that dryer is receiving correct voltage at Terminal Block (check dryer label)
2LONG/3SHORTFLASH Shorted or incorrect heater Replace Heater Dryer will stop
2LONG/4SHORTFLASH Open/brokenheater Replace Heater Dryer will still run
EX CEL DRY ER, INC 1 . 8 0 0 . 2 5 5 . 9 2 3 5 EX CEL DRY ER. COM ADM IN@ EX CEL DRY ER. COM
3 5 7 CHESTNUT STREET, EAST L ONG M EADOW , M A 0 1 0 2 8
02/2016 4
Dryer blows only cold air (non-ECO dryers)
1. Checkheatsettingoncontrol.
2. CheckforlooseconnectionstoHeatingElement.
3. Replace Heating Element.
Dryer has loss of air volume
1. Checkmotorspeedsettingoncontrol.
2. CheckforslowrunningMotororburningsmell.Ifso,replaceMotor.
3. CheckPre-Filterforlintbuildup.CleanbyremovingPre-Filterandrinseinwarm
waterthendryPre-Filterbeforereinstalling.
CODE CHART
CodesaredisplayedbytheflashingoftheredLEDlightinthesensoradjacent to theairoutlet.
Normal operation will be indicated by the red LED being on when not drying and off when hands are under the sensor.
