TROUBLE SHOOTING
PROBLEM: High Tension on all settings
SOLUTION: Remove the computer console and verify if the tension is cable that
comes from the computer console are properly connected to the cable that is come
from the rear frame. (See Diagram Below)
SOLUTION: Make sure part 15A is removed. (See Diagram Below)
SOLUTION: Place tension knob on tension level one, then pull cable 13 up as high
as you can, this will reset the tension.
MAINTENANCE & TROUBLE SHOOTING
