STEP 8
Look underneath the trampoline.
Locate the straps attached to the
underside of the frame pad. Position
each outer strap so that one strap is
on each side of the frame as shown.
Tie the outside straps sewn to the
Pad Joints to each side of the frame
as shown and attach the inner straps
to the near V-rings.
Repeat this step with the remaining
straps (not shown).
Using the included plastic tie, attach
the warning label (13) to the frame
near the point where jumpers will
climb onto and off the trampoline.
STEP 9
Attach all the Stakes(11) to each slot
of the pad as shown.
Congratulations! Your trampoline is
now fully assembled (put together).
Make sure that all parts are
securely attached. Familiarize
yourself and all users with the
trampoline, with the safety pre-
cautions, use and instructional
materials, and care and mainte-
nance instructions in this manual
before using the trampoline.
8
13
Outer Straps
Frame
Inner Straps
V-ring
9
11
