5.Inserttheboltthroughtheyokeandsecurewiththe
nylocnut.Theboltshouldbetightenedto44ft-lb
(60N-m).
6.ApplynuttypePro-Lock(1-840022)tothesetscrew .
Insertthesetscrewintotheyokeandtightento18
ft-lb(24N-m).
InstallingthewheelSpacers
(FR724only)
Refertotheinstructionsheetpackagedwiththespacers
InstallingtheDeck
Important:DoNottransportFrontrunnertractor
withoutandapprovedExmarkfrontmount
attachment.
1.Stoptheengine,waitforallmovingpartstostop,
engagetheparkingbrake,andremovethekey.
2.Rotatethefoldlocklever,locatedonthedeck,inthe
unlockedposition(Figure2).
Figure2
1.Foldlocklevershownintheunlockedpostion
3.Onthetractor,removethetworetainingpinson
hitchlatchessothelatchescanactuatefreely.Raise
theoorpanandlockinuprightposition(Figure3).
Figure3
1.Removetheretainingpinsfrombothhitchlatches
2.Floorpanshownlockedintheuprightposition
4.Alignthefrontframeofthemowerdecktothe
Frontrunnertractorhitch.
5.Manuallyliftuponthehitchtogetthebarsonthe
frontframestartedintothereceiversofthehitch.
6.Pushthefrontframetowardsthetractoruntilthe
twohitchlatchesseatintothe“secure”position.
7.Insertthehitchlatchretainingpinsintothehitchpin
lock.Thedeckisnowlockedontothetractor.
8.Reinstallthekeyandturntheswitchtothe“run”
position.DoNotstarttheengine.
9.Alignthecylinderrodendtothetopholeoftheoat
linkbracketandinsertthepinasshowninFigure4.
Insertthecotterhairpintolockthecylinderpininto
place.
