1.2.2 Aircraft Battery Installation
Take a fully charged battery
Insert the battery into battery
compartment, while pressing the
left and right edges of the battery
(As shown in illustration) push in,
until the battery buckles are fully
locked. You should hear buckle
locking sound
Battery and aircraft top should
be flush that confirms battery
is in place.
1.2.3 Intelligent Battery Functions
4
(1) Battery activation: The smart battery can only be used after being connected to
the APP and then activate according to the prompts for the first time.
(2) Power display: The battery has a power indicator, which can display the current
battery power levels.
(3) Upgrade mode: The smart battery can upgrade firmware. When the battery is in
the upgrade state, the first and last two battery indicators are solid on.
(4) Balanced Charging: During charging,the voltages of the battery cells are
automatically balanced.
(5) Overcurrent Protection: The battery stops charging or discharging automatically
once full charged .
(6) Overcharge Protection: The battery stops charging automatically once fully
charged.
(7) Over-discharge Protection: Discharging stops automatically to prevent excess
discharge.
(8) Short Circuit Protection: The power supply is automatically cut if a short circuit is
detected.
(9) Battery Cell Damage Protection: The EXO Pro App displays a warning message
when a damaged battery cell is detected.
(10) Hibernation Mode: When the battery is in the on state, if there is no connected
device, the battery will automatically shut down within 3 minutes; when the power
is less than 1%, short press the battery switch at this time. If the minimum power
indicator flashes and the battery cannot be turned on, the battery can wake up by
charging again.
(11) Communication: Information about the battery's voltage, capacity, and current
is transmitted to the aircraft.
1
2
3
3
1
2
