11
REPLACING THE DEBRIS FLAP
See Figure 9.
Replace the debris flap if it is worn.

Using a 10 mm wrench or socket, remove the hex nuts,
washers, and debris flap.

Install the new debris flap. This replacement part is
available from the place of purchase, or by calling
1-800-242-4672.

Replace washers and hex nuts.

Tighten securely.
ATTACHING THE STORAGE HANGER
See Figure 10.
There are two ways to hang the attachment for storage.

To use the hanger cap, push in the button and place the
hanger cap over end of the lower end attachment shaft.
Slightly rotate the cap from side to side until the button
locks into place.

The secondary hole in the attachment shaft can be used
for hang ing pur pos es as well.
STORING THE EDGER ATTACHMENT
Store the edger attachment in a well-ventilated place that is
inaccessible to children. Keep away from corrosive agents
such as garden chemicals and de-icing salts.
Fig. 10
BUTTON
HOLE
HANGER
CAP
SECONDARY
HOLE
MAINTENANCE
Fig.
9
HEX NUT
WASHER
DEBRIS FLAP
EDGER GUARD
