Expand-it UT15518F - Exploded View;Parts List

13
EXPLODED VIEW/PARTS LIST
* STANDARD HARDWARE ITEM — MAY BE PURCHASED LOCALLY
Key Part
No. Number Description Qty.
1 678018001 Blade Nut (M8)
......................................................................................
1
2 638017001 Cupped Washer
....................................................................................
1
3 638006005 Blade
.....................................................................................................
1
4 678011001 Flange Washer
......................................................................................
1
5 660887001 * Screw (10-24 x 5/8 in. Hex Hd.)
...........................................................
3
6 678263001 * Lock Washer (5 mm)
.............................................................................
3
7 678262001 Flange
...................................................................................................
1
8 940657011 Warning Decal
......................................................................................
1
9 940726004 Expand-it Logo Label
...........................................................................
1
10 308734001 Blade Guard (Includes Key Nos. 8-9)
.................................................
1
11 561382001 Debris Flap
...........................................................................................
1
12 678260001 Washer (6 mm)
.....................................................................................
2
13 678017001 * Hex Nut (10-24)
.....................................................................................
2
14 308485001 Plate with Stud
.....................................................................................
1
15 308484001 Wheel Arm
............................................................................................
1
16 678258001 * Washer (10 mm)
....................................................................................
3
17 308730001 Adjusting Knob with Hex Nut
...............................................................
1
18 678259001 * Hex Nut with Nylon Cap (5/16-18)
........................................................
1
19 660737001 * Hex Screw (10-24 x 1/2 in.)
..................................................................
1
20 638245001 Curb Guide
...........................................................................................
1
21 518377001 Guide Wheel
.........................................................................................
1
22 308483001 * Push Nut (10 mm)
.................................................................................
1
23 660641001 * Hex Screw (10-24 x 5/8 in.)
..................................................................
1
24 660642001 * Cap Screw (1/4-20 x 1.25 in.)
...............................................................
1
25 308210001 Gear Head Assembly
...........................................................................
1
26 308735001 Drive Shaft Assembly (Includes Key Nos. 27-28)
................................
1
27 940657007 Warning Decal
......................................................................................
1
28 940654019 Warning Label, UL
................................................................................
1
29 518019001 Hanger Cap
..........................................................................................
1
30 678020001 Holding Pin
...........................................................................................
1
983000931 Operator’s Manual
