Expert E051301 - Page 13

Range Resolution Accuracy
200Ω 0,1Ω ±(1.2%+5)
2kΩ 0.001KΩ ±(1%+5)
20kΩ 0.01KΩ
200kΩ 0.1KΩ
2MΩ 0.001MΩ ±(1.2%+5)
20MΩ 0.01MΩ ±(1.5%+5)
Resistance
Open Circuit Voltage: about 0.25V
Overload Protection: 250V DC/AC rms
Temperature (°C, °F)
Range Resolution Accuracy
-20°C ~ 1000°C 1°C -20°C~0°C±(5%+4)
0°C~400°C±(1%+3)
400°C~1000°C±(2%+3)
0°F~1800°F 1°F 0°F~50°F:±(5%+8)
50°F~750°F:±(1%-+6)
750°F~1800°F:±(2%+6)
Note:
1. Accuracy does not include error of the thermocouple probe.
2.Accuracyspecicationassumesambienltemperatureisstable
to ±1°C. For ambient temperature changes of ±5°C, rated
accuracy applies after 1 hour.
Capacitance
Range Resolution Accuracy
20nF 0.01nF ±(8%+10)
20nF 0.1nF ±(5%+5)
2µF 0.001µF
20µF 0.01µF
200µF 0.1µF
1000µF 1µF ±(8%+10)
Overload Protection:
200µF and 1000µF ranges: no overload protection
the other ranges: F 250mA/250V fuse
Open Circuit Voltage:
about 0.5V
Transistor hFE Test
Range hFE Test Current Test Voltage
PNP & NPN 0 ~ 1000 lb≈2µA Vce≈1V
Range Description Remark
The approx. forward
voltage drop will be
displayed.
Open Circuit Voltage:
about 1.5V
The built-in buzzer
will sound if the
resistance is less
thanabout30Ω.
Open Circuit Voltage:
about 0.5V
Diode and Continuity
Overload Protection: 250V DC/AC rms
For Continuity test :
Iftheresistanceisbelween30Ωand100Ω,thebuz-
zer may sound or may not sound. If the resistance
ismorethan100Ω,thebuzzerwon’tsound.
Range Resolution Accuracy
meter
200A
0.1mV/0.1A ±(1.5%+5)
meter
1000A
1mV/1A ±(1.5%+5)
Max. Input Voltage: 200mV
Frequency Range: 40Hz ~ 400Hz
Response: Average, calibrated in rms of sine wave
AC Current (with clamp)
