6
Assembly
3. Insert the central screw with the spacing
plate in the tripod head and fix it.
5. Screw the U-Mount to the tripod head. Tighten
the tripod legs with the knurled screw.
2. Assemble spacing plate and central
screw.
6. Friction adjustment of the coupling for
the height axis.
1. Spread the tripod legs, extend and clamp
them.
4. Insert the U-Mount into tripod head.
