Assembly
7. Friction adjustment of the coupling
for the azimuth axis.
9. Mounting the adapter plate on the
bottom side of the binoculars.
11. Hold the binoculars by the carrying
handle and tighten the fixing screws.
10. Insert the binoculars in the dovetail
guide of the U-Mount.
12. Balance the binoculars at the centre
of gravity.
8. 2 x ¼" connection thread on the
bottom side of the binoculars
