8-line Digital I/O to Ethernet Adapter
8
Item Description
IP address
4 numbers separated by dots, it can be
assigned
by the DHCP server if “DHCP client” is enabled.
Subnet mask
4 numbers separated by dots, can be
assigned by
the DCHP server if “DHCP client” is enabled.
Gateway address
4 numbers separated by dots, can be
assigned by
the DCHP server if “DHCP client” is enabled.
DHCP client
If disable, then IP address 、
Subnet mask and
Gateway address must be assigned manually.
Socket port of HTTP setup Port number for HTTP Setup Menu, default is 80.
Socket port of digital I/O
Port Number ：
：：
：
any number between 1 and
65536,except 80 and 81 （ which
have been
designated as the web pages）
Socket Type：
：：
：
TCP Server
, uses TCP protocol, passively waits for
Client.
TCP Client
, uses TCP protocol, actively connects to
Server.
UDP
, uses UDP protocol, exchanges packets with
