Extech Instruments BR200-2

BR200-BR250-EU-EN v7.4 2/14
3
Description
1 Signal output
2 Power Indicator
3 Power On/Off, Dimmer
4 Flexible tube
5 Camera head and LED’s
6 OK
7 Up arrow, video or jpg
8 Menu
9 Down arrow
10 Power On/Off
11 Power Indicator
12 USB Socket
13 Video output
14 SD card socket
15 Power supply socket
16 Reset
17 Signal input
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
