IR250-en-GB_V3.1 7/16 5
Field of View
As the distance from the object increases, the spot size of the area measured becomes larger. The
meter’s field of view is 6:1; in other words if the meter is 6 inches from the target (spot), the diameter
of the target must be at least 1 inch. Note that measurements should normally be made as close as
possible to the device under test. The meter can measure from moderate distances but the
measurement may be affected by external sources of light. In addition, the spot size may be so
large that it encompasses surface areas not intended to be measured.
Specifications
Range -20 to 260°C (-4 to 500°F)
Resolution 0.1°
Accuracy -20°C to -7°C (-4 to 20°F): ±4°C (7.5°F)
-7°C to 260°C (20 to 500°F): ±3% of reading or ±2.5°C /5°F (whichever
is greater)
Note: Accuracy is specified for an ambient temperature range of 18 to
28°C (64 to 82°F)
Emissivity Fixed 0.95
Field of View D/S = Approx. 6:1 ratio (D = distance; S = spot or target)
Laser pointer Class 2(II) laser < 1mW power; Wavelength is 630 to 670nm
IR Spectral response 8 to 14 m
Display Backlit LCD display with function indicators
Display update rate Less than 1 second
Operating Temperature 0°C to 50°C (32°F to 122°F)
Operating Humidity 80% Relative Humidity max.
Power Supply 9V battery
Automatic Power Off Meter shuts off automatically after 8 seconds
Weight 125g (4.4 oz)
Dimensions 80x31.7x137mm (3.15 x 1.25 x 5.4”)
Copyright©2009‐2016FLIRSystems,Inc.
Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform
ISO‐9001Certified
6
12
24
2mm
12mm
4mm
24mm
8mm
48mm
www.calcert.com sales@calcert.com1.800.544.2843
0
5
10
15
20
25
30
