CFI EXTEL EASY BUS 3 & CB BUS 3 - 07/2016
GB4
b.
Connection of an electric catch, lock and of a gate motor
The functions are only valid if the handset is picked up.
- An electric lock or strike may be connected to terminals 7 and 8 on the outdoor station.
The strike or lock will be controlled by a short press (1 sec.) on the key on the handset.
Important : It is essential that the electric latch or lock installed has a mechanical memory like all products
marketed by Extel. For the wiring diagram please consult the label on the back of the handset and the back of the
outdoor station.
- An automatic gate opener, may be connected to terminals 5 and 6 and the two «external control» terminals on
the automatic opener.
The automatic opening mechanism will be controlled by a short press (1 sec.) on the
gate on the handset.
c. Connecting an extra indoor station (CB BUS 3)
An additional CB BUS 3 handset can be connected in parallel to the nearest handset (terminals 3 and 4 only)
It is essential to ensure that the poles are correctly matched when connecting the handset.
6. TECHNICAL SPECIFICATIONS
a. Indoor unit (CB BUS 3)
• Reference: 710014
• Power supply: 18 V
• Consumption: 2W
• Dimensions (mm): 230x80x40
b. Power supply
• Tension : 230V~ 18 V 1500 mA
c. Outdoor unit (PL EASY BUS 3)
• Reference: 820013
• Operating temperature (approximate): from -10°C to + 45°C
• Protection Index: IP44
• Front dimensions (mm): 120x97x30
7. OPTIONS
Extra indoor unit: CB BUS 3
Any EXTEL electric catch
Any EXTEL electric lock
Any EXTEL gate motor
