Extraflame Divina Plus - Warm air of convection; Forced ventilation; Room air entrance

28
To ensure the correct and safe operation of the Comfort insert, when building the fireplace
it is necessary to respect the clearances between the insert and the inner walls of the
fireplace.
Considering the measurements given in the technical specifications, you need to account
for at least 50 mm of air space in the upper part and on the two sides.
NB: The exhaust outlet pipe must always be at a minimum distance of 5 cm from
inflammable parts.
Warm air of convection
It is necessary to let the heat (accumulated
inside the casing) go out. It must be done to
avoid the superheating of the insert.
Forced ventilation
The tangential fan blows in the room the
warm air created in the insert.
Room air entrance
To allows an air loop, it is necessary to
have an air entrance hole. For a better
convection if it has to be on the
bottom of the apparatus. The air will
be taken from the room where the
stove is installed.
5 cm
