Extraflame LP14 - Page 11

119
525
A
163 100
74
74
525
292
187
1368
941
662
708
750
B
D
C
E
TECHNICAL FEATURES
11
Chapter2
LP 20
A = AIR INTAKE PIPE Ø 60 mm
B = FLUE GAS EXHAUST PIPE Ø 120 mm
C = BOILER 1 “ FLOW/OUTLET
D = BOILER 1 “ RETURN/INLET
E = 3 BAR 1/2 “ SAFETY DRAIN
 gure 2.2
