Fig. 7 Plastic Bed Components (Power Actuator)
Actuator may be rotated 90°
on some models
UP
DOWN
ELECTRIC DUMP
RED from Battery
BLK from Battery
RED from Actuator
WHT from Actuator
Front of Vehicle
Electric Actuator
Plastic Bed
