Ezgo EXPRESS L4 - FRONT SUSPENSION AND AXLE MOUNTED STEERING

Repair and Service Manual
B
B
FRONT SUSPENSION AND AXLE MOUNTED STEERING
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 14 Axle Mounted Steering and Front Suspension Components
Part of Frame
Part of
Frame
Wave Washer
Bearing
Outer Snap Ring
Inner Snap Ring
Intermediate
Shaft with
U-Joints
Rack & Pinion
Unit
King Pin
Tube
Thrust
Washer
Spindle &
King Pin
Bushing
Formed
Axle
Tie Rod
Spacer
Rack Ball Joint
Rack Extension
Page E-11
