THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page D-4
Service Parts Manual
1 70886-G01 BRAKE PEDAL (INCLUDES ITEMS 2 - 4).......................................................... 1
2 70883-G01 PEDAL .......................................................................................................... 1
3 70257-G01 PAD............................................................................................................... 1
4 16409-G1 OVAL RIVET, 1/8" X 15/32" LG..................................................................... 6
5
6 70581-G01 FLANGED BUSHING.......................................................................................... 2
7 70676-G01 TORSION SPRING ............................................................................................. 1
8
9 70582-G01 SHOULDER BOLT, 3/8 - 16 X 4" LG (STAINLESS STEEL)................................ 1
10 00643-G1 WASHER, 3/8" .................................................................................................... 1
11 11098-G5 LOCK NUT, 3/8 - 16 ............................................................................................ 1
12
13 70113-G01 ADJUSTABLE RUBBER BUMPER ..................................................................... 1
14 11027-G1 LOCK NUT, 5/16 - 18 .......................................................................................... 1
15
16 30295-G8 LINKAGE ROD ASSEMBLY (INCLUDES ITEMS 17 - 19).................................. 1
17 30297-G8 THREADED ROD ......................................................................................... 1
18 10385-G4 CLEVIS YOKE ADJUSTABLE ...................................................................... 2
19 00544-G4 JAM NUT, 5/16 - 24....................................................................................... 2
20 10386-G3 CLEVIS PIN, 5/16" X 13/16" LG.......................................................................... 1
21 10387-G3 COTTER PIN, 3/32" X 3/4" LG........................................................................... 1
22
23 70415-G01 BRAKE BELLCRANK.......................................................................................... 1
24 70581-G01 FLANGED BUSHING.......................................................................................... 2
25 70410-G01 BELLCRANK SHAFT .......................................................................................... 1
26 12305-G1 RETAINING RING, 13/32" ID............................................................................... 2
27 10386-G3 CLEVIS PIN, 5/16" X 13/16" LG.......................................................................... 1
28 10387-G3 COTTER PIN, 3/32" X 3/4" LG............................................................................ 1
29
30
BRAKES - HYDRAULIC
