Ezviz C8W User Manual

10
Operations on the EZVIZ App
The app interface may be different due to version update, and the interface of the app
you installed on your phone shall prevail.
1� Live View
When you launch the EZVIZ app, the device page displays as shown below.
You can watch a live feed, take snapshots, record videos, or choose video
definition as needed.
F9XXXXXXX
Swipe left and right across the screen to see more icons.
Icon Description
Share. Share your device with anyone you want.
Settings. View or change the device settings.
Video History. View Recordings.
Snapshot. Take a snapshot.
Record. Manually start/stop recording.
Privacy Masking.
Definition. Select video resolution from Ultra HD, Hi-Def or
Standard.
Pan/Tilt . Rotate the camera to get broader field of view.
Speak. Tap the icon, and then follow the on-screen
instructions to talk to or listen to people in front of the
camera.
Active Defense. Sound the alarm to deter intruders.
Multi-screen Live. Tap to select window layouts.

Ezviz C8W Specifications

General

Number of lenses	1
Fixed focal length	4 mm
Maximum aperture number	1.6
LED type	IR
Certification	UL / FCC / CE / WEEE / REACH / RoHS / UKCA
DC output current	1 A
DC output voltage	12
Power source type	DC
Power consumption (max)	6 W
Mounting type	Wall
Product color	Black, White
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Intelligent Video Surveillance (IVS) system features	Human detection
Total megapixels	4 MP
Maximum resolution	2560 x 1440 pixels
Video compression formats	H.264, H.265
Noise reduction technology	3D noise reduction
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Cloud services supported	EZVIZ Cloud
Maximum memory card size	256 GB
Frequency band	2.4 - 2.4835 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth	20 MHz
Wi-Fi data rate (max)	72 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	EZVIZ Cloud Proprietary Protocol
Lens mount interface	M12
Pan range	0 - 352 °
Tilt angle range	0 - 95 °
Camera shutter type	Electronic
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/2.7 \

Weight and Dimensions

Depth	158 mm
Width	149 mm
Height	157 mm
Weight	510 g
Package depth	197 mm
Package width	205 mm
Package height	185 mm
Package weight	885 g
