4� Waterproof Kit Installation (Optional)
If the camera is installed outdoors or in humid environments, please use the waterproof kit.
1. Insert the gasket into the Ethernet port of the camera.
Ethernet Port Gasket
2. Thread A through the nut, the gasket and the endcap.
A BNut Gasket
Endcap
3. Tighten the nut and the endcap�
A BNut Endcap
4. Thread A into the Ethernet port of the camera and tighten the nut.
Ethernet Port A
5. Connect B to the LAN port of the router.
B
Router
