Faber e-MatriX 800 Installation Manual

Installation manual e-MatriX 800/1600 ST
5 < < < <
A = EA non-return valve
B = ½ or ¾ ”connector
C = ¼ ”1m pipe
D = Valve
E = To be cut from a ¼ pipe length
of 1 meter
F = Mesh filter
G = In-line (fine) filter
H = Control box
I = ¼ ”1.5m pipe
J = Engine e-MatriX
1 = Safety clip (11x)
2 = Brackets (2x) in-line filter
3 = Elbow coupling (4x)
