Machines elements
1 : operating trigger with variator
2 : rotational direction switch
3 : LED light switch
4 : LED - Light Emitting Diode
5 : knurled bit-lock ring (CL.V146)
6 : driving square with spring clip (CL.C1913)
7 : battery release button
8 : rubber protective pads
9 : charge and alarm indicators
10: charger terminals protective cover
SPARE PARTS
A: spare batteries (14,4 V: CL.BA14
– 19,2 V: CL.BA19)
B: universal charger (CL.CH919)
C: spare brushes kit (CL.CBN1) for (CL.C1913) only
Technical specifications
Machines CL.C1913D CL.V146D
Drive size Square 12,7 mm (1/2’’) Hexagon 6,35 mm (1/4’’)
Maximum torque 330 N.m 150 N.m
No-load motor voltage 19,2 V 14,4 V
No-load speed 0 - 2000 rev/min 0 - 2300 rev/min
Impacts per minute 2500 2600
Weight, battery excl. 2,0 kg 1,2 kg
The universal charger automatically detects the FACOM accumulators charging voltage (9.6 to 19.2
Volts). It automatically regulates when the accumulator is charged, preventing any damage if the set is
left powered-on after the required charging time.
Note: the CL.CH919
universal charger is compatible with all of FACOM electrically powered tools
(CL.P1210, CL.P1413, CL.V146
and CL.C1913)
Batteries CL.BA19 CL.BA14
Type Ni-MH Ni-MH
Nominal voltage 19,2 V 14,4 V
Capacity 2,6 Ah 2,6 Ah
Weight (battery alone) 1,1 kg 0,8 kg
Universal charger CL.CH919
Charge capacity 9.6 to 19.2 Volt for Ni-Cd and Ni-MH batteries
Temperature of use between 10 °C and 40°C
Dimensions (charger only) 180 x 116 x 67 mm
Weight (charger alone) 0,6 kg
