PAGE 8
C
ONTROLS AND FUNCTIONS
SEE FIGURES (1-5) ON PAGE 7
SEE FIGURE 1
1. MAIN POWER SWITCH: TURNS THE MACHINE ON AND OFF.
2. SPEED CONTROL KNOB: CONTROLS THE DRIVE SPEED ON THE MACHINE
3. REVERSE SWITCH: DEPRESS DOWN TO DRIVE IN REVERSE. REVERSE IS SET AT 50% SPEED FOR SAFETY.
4. LCD SCREEN: LISTS FUNCTIONS AND SETTINGS OF THE MACHINE.
5. MENU CONTROL: SCROLLS THROUGH DIFFERENT OPTIONS ON THE LCD DISPLAY.
6. BRUSH PRESSURE SELECTOR: CONTROLS THE PRESSURE PUT ON THE SCRUB DECK.
7. SCRUB DECK SWITCH: RAISES AND LOWERS THE SCRUB DECK.
8. SOLUTION CONTROL KNOB: CONTROLS THE SOLUTION FLOW RATE, WHEN SOLUTION SWITCH IS ON.
9. HANDLE BAR: USE BOTH HANDS WHEN OPERATING MACHINE.
10. DRIVE CONTROL BUTTONS: DEPRESS TO DRIVE FORWARD, AND RELEASE TO STOP.
SEE FIGURE
2
11. SOLUTION FILL SCREEN: PREVENTS DEBRIS FROM GETTING INTO SOLUTION TANK WHILE FILLING.
12. SOLUTION FILL LID: USED TO REFILL THE SOLUTION TANK WITH CLEANING SOLUTION.
SEE FIGURE
3
13. SQUEEGEE LIFT LEVER: ROTATE TO LEFT TO RAISE SQUEEGEE, AND TO THE LEFT TO LOWER SQUEEGEE.
14. RECOVERY TANK DRAIN HOSE: USED TO DRAIN DIRTY RECOVERY WATER FROM TANK, ALWAYS FLUSH OUT COMPLETLY.
15. CHARGER PORT: RED 50 USED TO RECEIVE CHARGER INPUT. NOTE: ONLY USE CHARGER PROVIDED.
16. SQUEEGEE PROTECTION WHEELS: HELPS PREVENT DAMAGE TO SQUEEGEE WHEN CLEANING CLOSE TO WALLS.
17. SQUEEGEE: RECOVERS DIRTY WATER FROM FLOOR. KEEP CLEAN AND REPLACE BLADES WHEN WORN
18. SQUEEGEE TRAILING WHEELS: QUIDES SQUEEGEE AND PREVENTS SWAING.
19. VACUUM HOSE: VACUUMIZES SQUEEGEE. NOTE: KEEP FREE AND CLEAR OF BLOCKAGE.
20. SOLUTION DRAIN HOSE: USED TO DRAIN SOLUTION TANK.
21. SOLUTION LEVEL INDICATOR TUBE: SHOWS OPERATOR THE PRECISE LEVEL OF CLEANING SOLUTION IN TANK.
SEE FIGURE
4
22. VACUUM COVER: PERMITS OPERATOR TO SEE FOAM, AND STOP BEFORE DAMAGE IS DONE TO VACUUM MOTOR .
23. FLUSH OUT TANK LID: PERMITS ACCESS TO FLUSH OUT RECOVERY TANK AFTER DRAINING.
24. RECOVERY TANK: HOLDS 30 GALLONS OF DIRTY RECOVERY WATER. MAX TEMP IS 140 F OR 60 C
25. BUMBER ROLLERS: HELP PROTECT THE MACHINE WHEN CLEANING CLOSE TO OBJECTS.
SEE FIGURE
5
26. CUP HOLDER: THE MACHINE IS EQUIPED WITH TWO CUP HOLDERS.
27. JAWS: PROTECT THE SCRUB DECK FROM BEING DAMAGED AND CONTROL SPLASHING. OPEN TO CHANGE BRUSHES.
28. DRIVE WHEELS: PROVIDE PROPULTION FOR MACHINE.
29. REAR CASTERS: TWIN CASTERS FOR STABILITY.
