Command type (Encoder 3)
Encoder types:
CCr1 control change command in relative mode 1 (values 1/127)
CCr2 control change command in relative mode 2 (values 63/65)
CCAb control change command in 7 bit absolute mode (values 0 to 127) mostly used as standard
PrGC program change command (values 0 to 127)
CCAh two control change commands (MSB/LSB) in 14 bit highres mode (values 0 to 16383)
Pbnd pitch bend command 14 bit (values 0 to 16383)
AFtt aftertouch (channel pressure) command 7 bit (values 0 to 127)
Push button / green button types:
OFF button sends no command
notE note command
CC control change command
PrGC program change command
AFtt aftertouch (channel pressure) command
(for all types: upper value = press/on, lower value = release/off)
Fader types:
CCAb control change command in 7 bit absolute mode (values 0 to 127) mostly used as standard
PrGC program change command (values 0 to 127)
Pbnd pitch bend command 14 bit (values 0 to 16383)
AFtt aftertouch (channel pressure) command 7 bit (values 0 to 127)
Command mode (Encoder 4)
Encoder modes:
Acc0 no acceleration by faster turning
Acc1 low acceleration by faster turning
Acc2 middle acceleration by faster turning
Acc3 max acceleration by faster turning
Fader modes:
SnAP sends command not before catching the last value by moving the control
JMP jump mode, command will be send immediately by moving the control
Push button modes:
btn send momentary command (upper value = press, lower value = release)
toGL send toggle command (upper value = on, lower value = off)
Command channel (Encoder 5)
Ch01....Ch16 choose midi channel 1 to 16
Command number (Encoder 6)
n000....n127 choose controller or note number 0 to 127 for note and CC commands
0 to 31 (MSB) for high resolution mode (32 to 63 for LSB follows automatically)
