page 12
230Vac output
for
flashing lamp
max 25W
Flashing lamp 230V:
2019
l'apricancello
DIP-SWITCH-A N°4 and N°7:
ON: Pre-flashing before movement
OFF: No pre-flashing
4
ON: Out of service in dwell phase
automatic mode (by Dip 3= ON)
OFF: Powered, ie. in service in dwell phase
automatic mode (by Dip 3= ON)
7
SINGLE- OR
THREE-PHASE
control board
230V - 400V
power supply
NEUTRAL
LIVE
SINGLE-PHASE
control board power supply
230V - 50/60Hz ±10%
DWELL TIME
1s - 220s
RUN TIME
OPEN - CLOSE
0s - 120s
-
+
-
+
Output for motors:
single-phase 230V
max 735W - 1,0 HP
or
three-phase 400V
max 1100W - 1,5 HP
24V Output :
FA D I N I
Astro 43
FA D IN I
24Vac OUTPUT max load:
No.3 pairs photocells
No.1 radio receiver
No.1LED Chis 37 / Chis-E 37 key-switch
Instructions are attached to the related
control accessories
12 13
meccanica
FADINI
37
Accessory
Electrical connections
Dip-Switch setting and LED indication of functions
SINGLE-PHASE
ELECTRIC MOTORS
power supply
M1
common
16 17 18
CAPACITOR
THREE-PHASE
ELECTRIC MOTORS
power supply
M1
common
16 17 18
230V
21 22 23
LIVE
THREE-PHASE
control board power supply
400V - 50/60Hz ±10%
21 22
23
LIVE
LIVE
400V
SINGLE – THREE PHASE ELECTRONIC CONTROL BOARD WITH ELECTRONIC BRAKE
FOR SLIDING GATE AUTOMATIC SYSTEMS WITH OR WITHOUT LIMIT SWITCHES
GB
