Place the mounting bracket on furniture board and position it accordingly (Fig. 12).
The distance between the furniture board and the underside of the worktop should
be 5 mm (Fig. 13). Attach the mounting bracket using suitable screws supplied in
the installation kit. Pull out the mounting bracket cover and screw in the two special
screws (2) in the appliance doors(Fig. 14). Attach furniture board with the xed
mounting bracket to the appliance door. Secure the furniture board with suitable
nuts (item 3, Figure 14). Make sure the furniture board assembly is positioned
correctly relative to the appliance (Fig. 15). Using the supplied screws, attach the
furniture board assembly to the bottom of the appliance door (Fig. 15). Replace the
mounting bracket cover in its original location.
