Identification
9
1
0
2
Installation
Operation
The mains water pressure should be between 0.05 and 1 Mpa (0,5 a 10 kg/cm
2
).
Do not use extension leads or adapter plugs to connect the washing machine.
The electrical installation must not exceed the voltage indicated on the reference plate
and the mains connection must have the regulatory earth connection.
If the electrical cord is damaged it must be replaced by your after-sales service or
similar qualified staff, to prevent hazard.
Do not tamper with the inside of the washing machine. In case of any problems you
cannot solve yourself, call the technical assistance service.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance. Cleaning and user maintenance shall not be made by children without
supervision
Identify your washing machine model (“a”, “b”, “c”,
“d” or“e”) by comparing the control panel with the
illustrations.
1.1 Unpacking (1.1.1, 1.1.2 and 1.1.3). Remove the
bolts and the fixing and blocking elements used for
transport.
1.2 Connection to the water mains (1.2.1, 1.2.2 and
1.2.3). If the washing machine has a hot water intake,
connect the hose with a red connector to the hot
water intake (1.2.4). Always use the new hose
supplied, removing any previously used hoses.
1.3 Drain. Place the hose in the drain in accordance
with the measurements shown on the drawing.
1.4 Levelling. Correctly level the washing machine to
prevent any noise or shifting. The recommended
procedure is as follows: 1. Position the rear legs and
fix them in place (1.4.1); 2. Place the washing
machine in its final location (1.4.2); 3. Position the front
legs and fix them in place (1.4.3).
1.5 Electrical connection. Take the electrical data on
the reference plate into account.
1.6 Installation under a worktop. If you need to
remove the worktop to recess-mount the washing
machine, contact your dealer or the Technical
Assistance Service. For recess-mounted washing
machines, the electrical plug must be accessible
after installation.
Recess dimensions are 600x600x850.
2.1 Opening the loading door. Open the loading door.
2.2 Detergent and additives. Sort items by colour,
soil and fabric type before loading the washing
machine.
The detergent drawer has the following
compartments: wash , prewash and
fabric softener (2.2.1).
All the washing machines are designed to use
powder detergent (2.2.2). If you wish to use liquid
detergent (2.2.3), you will see a blue tab for this
purpose in the wash compartment. Pull it outwards
as far as it will go, then release it. It will remain in
vertical position (2.2.4), this will prevent the liquid
detergent from running out. To use powder
detergent again, place the blue tab in horizontal
position and push it back as far as it will go to open
the flap (2.2.5).
Remember you must not exceed the MAX level
marked on the fabric softener compartment.
2.3 Switching on the washing machine and
selecting a programme. Select the programme
using the dial, after consulting the programme chart
(pages 11 and 12).
2.4 Selecting the spin speed. You may choose a spin
drying speed or cancel out spin drying (2.4.1,
2.4.2). If you select Rinse hold (2.4.3) the wash
process will pause before the final spin and the
clothes will be left submerged in water. Press to
run the final spin dry.
Safety
This appliance is for domestic use only and designed for washing clothes.
Very important: Please read the whole of this manual before installing and using the washing machine.
You will find the documentation and accessories inside the drum.
The texts in the manual correspond to the numbered diagrams.
Instruction manual
english
