Fagor RFA-244 DF - 3 Using the Gas Cooktop; Burner Layout; Main Parts of the Gas Cooktop

20
3. USING THE GAS COOKTOP
RFA-244 DF RFA-365 DF
1. Semi-Rapid 1. Semi-Rapid
2. Semi-Rapid 2. Semi-Rapid
3. Dual Burner 3. Rapid
4. Auxiliary 4. Dual Burner
5. Auxiliary
1. Cast Iron Grate 4. Spark plug
2. Burner cap 5. Safety valve (for models equipped with it)
3. Burner head 6. Knob
BURNER LAYOUT
MAIN PARTS OF THE GAS COOKTOP
3.1
3.2
2
5
4
3
1
1
3
2
4
