Fanco Studio DC - Light Diffuser Installation

Light Plate Installation
Light Diffuser Installation
Screw hole
alignment scr ew
Tighten
Rotate into position and
tighten the screw
A
Tighten screws
B
Insert wire into lamp plate
C
Align the lock points
A
Gently twist diffuser into place
B
8
