Fanco Studio DC - ELECTRICAL CONNECTIONS; WIRING DIAGRAM - WITH REMOTE; WIRING DIAGRAM - WITH WALL CONTROL

4
ELECTRICAL CONNECTIONS
• Ensure the power is off when installing this fan.
Double pole disconnection switch or 2 pin plug
Wall Switch
E
L
N
C
2
1
Power Supply-Live Wire Brown
Power Supply-Neutral Wire Blue
Ground Wire Yellow /Green
E
L
N
L in L out
Double pole disconnection switch or 2 pin plug
Wall Switch
Power Supply-Live Wire Brown
Power Supply-Neutral Wire Blue
Ground Wire Yellow /Green
WIRING DIAGRAM - WITH REMOTE
WIRING DIAGRAM - WITH WALL CONTROL
