Fanco Studio DC - INSTALL CEILING BRACKET

5
nut
rubber
wire hole
Hole :
Dia 8mm
Deep 50mm
ceiling
Bracket
ceiling
ceiling ceiling
ceiling ceiling
Align the rubber
& nut with the
bracket
Use screws to fix the
parts together
Complete
Use the bracket as
a guide to mark
required screw
holes
Drill Holes
place
expanding
screws into
the holes
Place bracket over
expanding screws
Tighten screws
Hanger installation
completed
A
B
C
D
E
F
G
H
INSTALL CEILING BRACKET
