- 6 -

When installing the relay for 3-phase photovoltaic instal-

lations, it is recommended to connect the CP-721-FPV

relay to the phase with the highest voltage overshoot,

or to use a separate relay for each phase and control the

load via an additional phase switch. An example wiring

diagram is shown in the figure below:
